Exchange SE Kerberos Authentication Failure: Missing ASA Credential

Maynor in the Cloud / Beyond the Tenant

The new Exchange servers looked ready. The authentication dependency was not.

Problem

We were introducing new Exchange Server Subscription Edition servers into an existing Exchange environment.

Before moving production traffic, we tested the new servers directly by overriding name resolution with host-file entries. The goal was to point the existing Exchange namespaces to the new servers and validate OWA, ECP, and the other virtual directories before changing production DNS or the load balancer.

OWA and ECP reached the new servers, but authentication failed.

The URLs were correct. The virtual directories were there. The servers were reachable.

The failure was happening during authentication.

Symptoms

OWA authentication failures
ECP authentication failures
Kerberos-related errors during testing
Failures only when traffic was directed specifically to the new Exchange SE servers

That last point mattered. The issue followed the new servers.

Investigation

Once we confirmed the virtual-directory configuration and connectivity looked right, we worked backward through the authentication path.

The problem initially looked like an SPN issue because Kerberos was not completing successfully.

That led us into Active Directory and the Exchange Kerberos configuration.

The environment already had an ASA-based Kerberos configuration associated with the Exchange namespace. But the ASA credential had not been rolled out to the newly introduced Exchange SE servers.

Exchange Namespace

→

SPN / ASA Identity

→

ASA Credential on Exchange Server

Kerberos Authentication

→

OWA / ECP

Figure 1. The namespace and service identity can exist while the new server is still missing the ASA credential required to participate in Kerberos authentication.

Root Cause

The Exchange organization was already using an Alternate Service Account for Kerberos authentication, but the ASA credential had not been deployed to the newly introduced Exchange SE servers.

The new servers could receive requests for the existing Exchange namespace, but they had not been provisioned with the ASA credential used by the existing Kerberos configuration.

The Kerberos service identity existed, but the new Exchange servers had not been given the ASA credential required to participate in that authentication configuration.

Validate the ASA Configuration

The first step was to compare the ASA state on the Exchange servers.

Get-ClientAccessService <NewExchangeServer> `
    -IncludeAlternateServiceAccountCredentialStatus |
    Format-List Name,AlternateServiceAccountConfiguration

The important question is not simply whether Kerberos is configured somewhere in the organization. It is whether the server you are about to place into service has the expected ASA configuration.

Resolution

The existing ASA credential needed to be copied from a working Exchange server to the new Exchange SE server.

.\RollAlternateServiceAccountPassword.ps1 `
    -ToSpecificServer <NewExchangeServer> `
    -CopyFrom <ExistingExchangeServer>

NOTE: Validate the script syntax against the Exchange SE version in use before running it in another environment.

Validation

We went back to the same test that originally exposed the problem.

Do not validate a fix with a different test than the one that failed.

Using the host-file override, traffic was again directed specifically to the new Exchange servers and the affected virtual directories were retested.

Validation needed to prove:

the new server had the expected ASA credential
OWA authentication worked
ECP authentication worked
Kerberos authentication completed successfully
the existing Exchange namespace continued to function as expected

Why This Is Easy to Miss

When adding or replacing Exchange servers, several obvious items normally get attention:

certificates
virtual-directory URLs
namespaces
SCP configuration
load-balancer configuration
DNS
connectivity

Those can all be correct while Kerberos still fails.

The ASA credential is different because it is part of the existing authentication architecture but also has state that must be present on the individual Exchange servers participating in it.

The Troubleshooting Lesson

The most useful part of this incident was not the command that fixed it.

It was the way the problem was found.

We did not wait until production cutover to discover that authentication was broken. We forced the production namespace toward the new Exchange servers during validation and tested the actual user-facing services before placing those servers behind production traffic.

When a new Exchange server joins an existing shared namespace, validate the dependencies of that namespace—not just the server configuration. If Kerberos uses an ASA credential, every new server expected to service that namespace must be validated for that credential before it receives production traffic.
